Ubiquiti UniFi USW-Pro-Max-24

MechanicalDimensions442 x 325 x 44 mm (17.4 x 12.8 x 1.7″)WeightWithout mounting brackets: 4.2 kg (9.3 lb)
With mounting brackets: 4.3 kg (9.5 lb)Enclosure materialSGCC steelHardwareManagement interfaceEthernet In-BandNetworking interface(16) GbE RJ45 ports
(8) 1/2.5 GbE RJ45 ports
(2) 10G SFP+ portsTotal non-blocking throughput56 GbpsSwitching capacity112 GbpsPower method(1) Universal input, 100—240V AC, 50/60 Hz
(1) USP-RPS DC inputPower supplyAC/DC, internal, 50WSupported voltage range100—240V ACMax. power consumption50WLCM display(1) 1.3″ touchscreenButtonFactory resetAmbient operating temperature-5 to 40° C (23 to 104° F)Ambient operating humidity10 to 90% noncondensingCertificationsCE, FCC, ICSwitching FeaturesLayer 2 featuresIGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLsLayer 3 featuresDHCP for locally-managed networks
DHCP relay
Inter-VLAN routing between networks on same switch
Static routing between local networks
Network isolation with ACLsEtherlighting™EthernetLocating
Speed/link
Native VLAN/networkSFP+Locating
Speed/link
Native VLAN/networkLEDsSystemStatusRPSStatusApplication RequirementsUniFi NetworkVersion 8.0.24 and later
